REDARC Anderson Series Cable (SRC0011)
REDARC Anderson Series Cable (SRC0011)

REDARC Anderson Series Cable (SRC0011)

£41.86
Out of Stock - Please call to order
Get notified by email when this product is in stock.

The 0.3m Anderson™ Series Cable is used to connect multiple solar panels together in series, increasing your total panel voltage.

With genuine industry standard Anderson™ SB™50 connectors, set up is easy. These high quality Anderson™ plugs are simple and fast to connect with no screw terminals and no risk of poor connections from frayed wires or loose terminals – just plug and play!

Specifications

  • Insulation/ Sheath: UV Stabilised PVC
  • Voltage Rating: 50V DC max
  • Conductor: Bare Copper
  • Current Rating: 40A
  • Wire Gauge: AWG 11 (Ø2.3 mm)
  • Cable Length: 300 mm (±10 mm)
  • Warranty: 2 Years
  • Connector Type: Series Anderson™ SB™ 50, Anderson™ SB™ 50

REDARC part number: SRC0011
