The REDARC BCDC1225D In-vehicle Battery Charger is a 12V 25A In-vehicle DC to DC battery charger.
Featuring a Maximum Power Point Tracking (MPPT) solar regulator, the BCDC1225D will charge from both solar and the alternator simultaneously. And, with built-in 'Green Power Priority' it will select solar charging first, meaning less load on the alternator.
Suitable for 12 or 24-volt vehicle systems, the unit will also work with either standard or variable/smart alternators.
The BCDC1225D features the same patented charging profiles as it’s predecessor along with a new lithium charging profile making the unit suitable for charging AGM, Gel, Standard Lead Acid, Calcium and LiFePO4 batteries, perfect for pairing with a REDARC Lithium battery.
For most applications, the BCDC1225D is suitable for battery bank sizes of 75-200AH. For higher capacity needs of over 200AH, REDARC recommends the BCDC1240D.
Proven and Tested
The award-winning technology in the BCDC has been independently verified and tested to ensure battery life is maximised, charging your battery to a proven 100%.
Features
- Separate DC and solar charging inputs
- Maximises the performance and life of your auxiliary battery
- Simultaneous DC and solar charging with Green Power Priority
- Suits 12V/24V standard and variable voltage/smart alternators
- Suitable for AGM, GEL, standard lead acid, calcium and Lithium (LiFePO4) batteries
Specifications
- Input (Operating) Voltage: 9 - 32VDC
- Output System Voltage: 12VDC
- Maximum Charging Voltage: 15.3V
- Output Current Rating (Cont.): 25A
- Input Fuse Rating: 40A
- Output Fuse Rating: 40A
- Type Approval: E-Mark
- Warranty: 2 Years
- Standby Current Draw: <100mA
- Output Power: 375W
- Width (mm): 120
- Height (mm): 37
- Length (mm): 165
- Weight (kg): 1
Downloads
REDARC part number: BCDC1225D
